This hermetic socket with Insulating Medium of Glass-to-Metal Seals Rectangle 9 Pins Micro D Connector also call multipin feedthrough. It is Micro-D type multipin feedthrough with 9pins, 375Volts, 1Amps per pin, Weldable Mount.
| Number of Conductors | 9 |
| Style | Micro-D |
| Voltage | 375 Volts |
| Current | 1.0 Amps |
| Mount Style | Weld |
| Conductor Diameter | 0.5mm |
| Conductor Material | Stn Stl |
| Temperature Range | -269 to 450 ℃ |
| Pressure Range | 1450 psi |
Innovacera develops many kinds of Ceramic-to-Metal Sealing products, including this 9pins Micro D Connector.
It is available for customized drawing.
Declaration: This is an original article of INNOVACERA®. Please indicate the source link when reprinting: https://www.innovacera.com/product/micro-d-connector
Frequently Asked Questions
Why Choose Glass-to-Metal Sealed Micro-D Connectors? How Do They Maintain Hermeticity from -269°C to 450°C?
Standard plastic or elastomer Micro-D connectors outgas severely, degrade, and leak under vacuum bakeouts and cryogenics. INNOVACERA’s 9-pin Micro-D hermetic connector uses advanced glass-to-metal / ceramic-to-metal sealing technology to create a permanent, leak-tight glass insulator body with stainless steel conductors. Rated for 375V and 1.0A per pin under pressures up to 1450 psi, it withstands thermal extremes from -269°C to 450°C without signal degradation or seal breakdown in ultra-high vacuum (UHV) systems.
Need High-Density Pinouts for Vacuum Instrumentation? How to Order Custom Micro-D Feedthroughs from INNOVACERA?
Space-constrained vacuum chambers and sensors often require tailored mounting flanges and pinout layouts. INNOVACERA provides full custom engineering for Micro-D multipin feedthroughs, offering weldable mounts, standard flange integration (such as CF or KF), specialized pin lengths, and alternative pin counts. Customers can submit their pinout requirements, CAD drawings, and operating pressure limits to receive dedicated engineering feedback and rapid sample fabrication.
