These photodetector ceramic packages are intended for light-receiving devices such as photodiodes, avalanche photodiodes (APDs),infrared detectors,optical sensors,and other optical receiving components. Unlike general-purpose IC packages,photodetector packaging must account for optical access,detector position,cavity geometry,light shielding,and PCB interface requirements in addition to chip mounting and electrical connection.
Alumina ceramic offers electrical insulation,mechanical rigidity,dimensional stability,and compatibility with metallization processes,making it well suited to compact optoelectronic assemblies that require precise positioning and reliable integration.
Applications
- Photodiode Modules
- Avalanche Photodiode (APD) Assemblies
- Infrared Detector Modules
- Optical Sensor Packages
- Laser Receiver Modules
- Fiber-Optic Receivers
- Optical Communication Receivers
- LiDAR Receiver Systems
- Spectroscopy Instruments
- Gas Detection Systems
- Industrial Optical Sensing Equipment
- Medical Optical Detection Equipment
Product Features
Designed around the integration needs of optoelectronic photodetectors, from chip mounting and electrical connection to optical access and package geometry.
| Feature | Description |
|---|---|
| Compact SMD Package Structure | Surface-mount design supports compact PCBs and miniaturized photodetector modules. |
| Stable Detector Mounting Platform | The rigid ceramic body provides a stable mounting area for photodiodes, APDs, and other detector chips. |
| Electrical Insulation | Alumina ceramic provides reliable electrical isolation between the detector chip, metallized conductors, and external terminals. |
| Custom Metallization Design | Metallized areas can be configured for die attachment, wire bonding, signal routing, and external SMD terminal connections. |
| Optical Opening Design | The cavity and optical opening can be designed around the detector optical path and active sensing area. |
| Light-Shielding Structure | Cavity walls and package geometry can be designed to reduce stray-light interference around the active detector area. |
| Dimensional Stability | Stable ceramic geometry helps maintain consistent positioning of the chip, bonding areas, and external connections. |
| Custom Package Configuration | Package dimensions, cavity geometry, terminal layout, metallization pattern, and optical opening can be tailored to project requirements. |
Customization & Technical Support
INNOVACERA can support ceramic package design and manufacturing based on the detector structure, package dimensions, metallization layout, and assembly process.
For new projects, please provide the chip dimensions, package drawing, cavity structure, terminal layout, bonding method, optical opening, and assembly requirements. Our engineering team can review the package structure and evaluate a suitable design for your application.
