Silicon nitride ceramic glow plugs are used for diesel engine start-up preheating and ignition of various high-temperature gases. This product uses silicon nitride ceramics as the base material of the heating part, which overcomes the problems of metal sleeve-type glow plugs, such as not resistant to high temperatures, short service life, and long pre-heating time .
The following is the detailed information of our products:
Electrical properties
- *Rated Voltage：8V，12V，16V，18V，24V
- *Frequency：50/60HZ
- *Rated power：35W～750W
Advantages
- Long service life: Service life reaches 15000 hours;
- Power on and off times: 105 times;
- Fast preheating: when the preheating temperature reaches 1000°C, the preheating time is 3-5 seconds;
- Good low temperature startup performance: reliable startup at -30°C;
- High temperature strength:suitable for high-speed diesel engines and high- temperature ignition devices.
Applications：
- High speed diesel engine
- High temperature ignition device
- parking heater
- Car preheater
- Car exhaust treatment
Performance Comparison of Silicon Nitride Glow plug and Metal glow plug
| ITEM | Si3N4 Glow Plug | Metal Glow Plug |
| Pre heat temp(℃) | 1000-1200 | 800-900 |
| Pre-heat time(S) | 5-8 | 20-40 |
| Power(W) | ≤45 | 100 |
| Power on-off time | 105 | 240 |
| Low temp startup performance:(℃) | -30 | -5 |
Si3N4 Glow Plug Specification:
| Max
temp(℃)
|
Working temp
(℃) |
Thermal conductivity
(20℃)Kcal/m·h·℃
|
specific heat
J/(kg.k)
|
Thermal expansion coefficient(℃)
|
| ＜1300 | ＜1200 | 25 | 640 | 3.4×10-6 |
If you have any question about the silicon nitride glow plug, welcome to contact us at sales@innovacera.com.
