Innovacera develops all kinds of ceramic grinding media balls such as silicon nitride grinding balls, alumina ceramic grinding balls, zirconia grinding media balls which are a important grinding media in the industrial production and laboratory research. Ceramic grinding media, ceramic grinding balls also call ceramic grinding beads, ceramic grinding media or ceramic grinding bodies which is widely use in the fields need better grinding, polishing, and mixing processes.
Ceramic Grinding Media Balls Features:
Effectively crushes and refines materials
High grinding efficiency
Abrasion is very low
Outperforms in durability compare to traditional grinding media
Maintaining shape and dimensional stability over extended periods.
High Chemical Stability
Low Contamination
Generates minimal harmful substances during grinding
Ceramic Grinding Media Balls Applications:
Ultra-fine grinding and dispersion of high-purity powders, such as silicon nitride ceramic powder.
Pharmaceutical
Aerospace
Metallurgy and Mining
Laboratory Research
Grinding and dispersing high-hardness materials, such as quartz.
Electronics
Optics
Coatings and Paints
Cosmetics
Ceramic Grinding Media Balls Material Properties Comparison:
Ceramic Grinding Media Balls Performance Comparison:
| ZrO2 | Al2O3 | Si3N4 | SiC |
| zirconium oxide (ZrO2)， yttria (Y2O3) | aluminium oxide ( High Purity） | silicon nitride (Si3N4) | silicon carbide (SiC) |
| 6.0 g/cm³ | 3.75-3.95 g/cm³ | 3.2 g/cm³ | 3.0 – 3.2 g/cm³ |
| low, 2-3 W/m·K | middle，20-30 W/mK | 15 – 50 W/mK | high, 100–120 W/m·K |
| 5-6 kgs/Ton | Very High | Low | Very Low |
| Used in various grinding processes such as ball milling and abrasive wear, which require high wear resistance and minimal contamination, including applications in ceramics, pigments, pharmaceuticals, and cosmetics. | As grinding media in ball mills, Chutes, pipelines, and pump impellers. Thermocouple protection in furnaces. |
Request hard material grinding and high-temperature grinding processes, high wear resistance, such as in silicon nitride ceramic powder, metal processing in the automotive industry. | Metal precision finishing, ceramic grinding, and glass cutting. |
Ceramic Grinding Media Balls Sintering Way Comparison:
| Gas Pressure Sintering (GPS) | Hot Isostatic Pressing Sintering (HIP) | |
| Sintering Condition | Temperature: 1800–1900℃ | Temperature: 1800–1900℃ |
| Sintering atmosphere pressure: 10 MPa | Sintering atmosphere pressure: 200 MPa | |
| Degree of Densification | Residual minor porosity (99.2%) | Near full densification (99.8%) |
| Performance Indicators | Meet Grade II–III Ball Standards | Performance indicators and fatigue life are significantly improved compared to GPS. |
| ASTM F2094-2011 (USA) | Grade III | Grade I, II |
| Grade | Medium–Low Pressure Ceramic Balls | High-End Ceramic Balls |
| Remarks | Technology predominantly used domestically | Commonly adopted internationally, but with high costs, not suitable for large-scale industrial production. |
Ceramic Grinding Media Balls Production Process:
Ultra-fine High-purity Silicon Nitride Powder, Sintering Aids, Additives → Homogeneous Mixing → Spray-dried Granules → Cold Isostatic Pressing (CIP) → Green Body Machining → Sintering (Isostatic Pressing (HIP) or Gas Pressure Sintering (GPS))→Balls Blank Inspection→Coarse Grinding, Precision Grinding, Ultra-fine Processing.
If you need the ceramic grinding media balls such as silicon nitride grinding ball, alumina and zirconia ceramic media balls, contact us Innovacera team at sales@innovacera.com.
